10-84-4060
Manufacturer:
Molex
Mfr.Part #:
10-84-4060
Datasheet:
Description:
Headers and Wire Housings Through Hole Header Number of Positions:6 Pitch:6.35 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 600 V |
| Length | 20.32 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Height | 13.97 mm |
| Packaging | Bulk |
| Voltage Rating | 600 V |
| Depth | 13.97 mm |
| Halogen Free | Low Halogen |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 6.35 mm |
| Insulation Resistance | 100 MΩ |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 6.35 mm |
| Current Rating | 13.5 A |
| Max Current Rating | 11 A |
| Flammability Rating | UL94V-2 |
| Number of Circuits | 6 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 1 year ago) |
| Color | Natural |
| Gender | Pin (Male) |
| Number of Contacts | 6 |
| Connector Type | Header |
| Number of Positions | 6 |
| Number of Rows | 3 |
| Row Spacing | 6.35 mm |
| Housing Material | Nylon |
| Fastening Type | Ramp |
| Contact Resistance | 3.5 mΩ |
| Max Voltage Rating (AC) | 600 V |
| Housing Color | Natural |
| glow wire compliant | Non-compliant |
| Contact Gender | Male |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 1 year ago) |
| Country of Origin | US |
| Termination Post Length | 4.3 mm |
Stock: 984
Distributors
pcbx
pcbxUnit Price$0.73182
Ext.Price$0.73182
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.73182 | $0.73182 |
| 10 | $0.60358 | $6.03580 |
| 25 | $0.59674 | $14.91850 |
| 50 | $0.59417 | $29.70850 |
| 100 | $0.55229 | $55.22900 |
| 300 | $0.51007 | $153.02100 |
| 500 | $0.47107 | $235.53500 |
| 1000 | $0.43516 | $435.16000 |
