100SGV22M10X10.5
Manufacturer:
Rubycon
Mfr.Part #:
100SGV22M10X10.5
Datasheet:
Description:
Aluminum Electrolytic Capacitors SMD,10.00mm×10.50mm SMD/SMT 22 µF 20 % 100 V
| Parameter | Value |
|---|---|
| Capacitance | 22 µF |
| Tolerance | 20 % |
| Life (Hours) | 2000 Hours |
| Ripple Current | 90 mA |
| Height - Seated (Max) | 10.31 mm |
| Diameter | 10 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Reel |
| Voltage Rating | 100 V |
| RoHS | Compliant |
| Ratings | AEC-Q200 |
| Ripple Current @ Low Frequency | 90 mA @ 120 Hz |
| Ripple Current @ High Frequency | 135 mA @ 10 kHz |
Stock: 8556
Distributors
pcbx
pcbxUnit Price$0.63174
Ext.Price$0.63174
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.63174 | $0.63174 |
| 10 | $0.40046 | $4.00460 |
| 25 | $0.34904 | $8.72600 |
| 50 | $0.30422 | $15.21100 |
| 100 | $0.27368 | $27.36800 |
| 300 | $0.25172 | $75.51600 |
| 500 | $0.23153 | $115.76500 |
