100YXG820MEFC18X40
Manufacturer:
Rubycon
Mfr.Part #:
100YXG820MEFC18X40
Datasheet:
Description:
Aluminum Electrolytic Capacitors 18.00mmD×40.00mmH Through Hole 820 µF 20 % 100 V
| Parameter | Value |
|---|---|
| Capacitance | 820 µF |
| Packaging | Bulk |
| Mounting Style | Through Hole |
| operating temperature | -40.0 °C |
| rohs status | Compliant |
| reach svhc compliance | No SVHC |
| size height | 40.0 mm |
| voltage rating dc | 100 V |
| capacitance tolerance | 20 % |
| size diameter | 18 mm |
| Tolerance | 20 % |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| RoHS | Compliant |
| Voltage Rating | 100 V |
| Life (Hours) | 6000 Hours |
| Diameter | 18 mm |
| Lead Pitch | 7.5 mm |
| Height - Seated (Max) | 42 mm |
| Ripple Current @ High Frequency | 2.33 A @ 100 kHz |
| Impedance | 36 mΩ |
| Ripple Current @ Low Frequency | 1.398 A @ 120 Hz |
Stock: 1
Distributors
pcbx
pcbxUnit Price$0.87802
Ext.Price$0.87802
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.87802 | $0.87802 |
| 10 | $0.85882 | $8.58820 |
| 25 | $0.85283 | $21.32075 |
| 50 | $0.84688 | $42.34400 |
| 100 | $0.84099 | $84.09900 |
