1447385C
Manufacturer:
Murata
Mfr.Part #:
1447385C
Datasheet:
Description:
Fixed Inductors 24.40mmD×14.00mmH Through Hole 47 µH 15 % 8.5 A 21 mΩ
| Parameter | Value |
|---|---|
| Tolerance | 15 % |
| Height - Seated (Max) | 15.5 mm |
| Length | 14 mm |
| Termination | Radial |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 2 |
| Composition(Kit Type) | Wirewound |
| Height | 15.5 mm |
| Packaging | Bulk |
| Depth | 25.9 mm |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 23.8 mm |
| REACH SVHC | No SVHC |
| Lead Length | 10 mm |
| Lead/Base Style | Radial |
| Self Resonant Frequency | 6.7 MHz |
| Type | General Purpose |
| Q Factor | 33 |
| Current Rating | 8.5 A |
| DC Resistance (DCR) | 21 mΩ |
| Test Frequency | 1 kHz |
| Orientation | Vertical |
| Military Standard | Not |
| Shielding | Unshielded |
| Inductance | 47 µH |
| RMS Current (Irms) | 8.5 A |
| inductance tolerance | 15 % |
| Max DC Current | 8.5 A |
| DC Current | 8.5 A |
| Saturation Current | 8.5 A |
| Schedule B | 8504500000 |
Stock: 365
Distributors
pcbx
pcbxUnit Price$1.55779
Ext.Price$1.55779
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.55779 | $1.55779 |
| 10 | $1.53918 | $15.39180 |
| 25 | $1.52671 | $38.16775 |
| 50 | $1.48915 | $74.45750 |
| 100 | $1.41407 | $141.40700 |
| 300 | $1.31687 | $395.06100 |
| 500 | $1.22636 | $613.18000 |
| 1000 | $1.15754 | $1157.54000 |
