15244449
Manufacturer:
Molex
Mfr.Part #:
15244449
Datasheet:
Description:
Headers and Wire Housings Through Hole Header Number of Positions:4 Pitch:5.08 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 250 V |
| Length | 23.26 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bulk |
| Depth | 8.28 mm |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Lead Pitch | 5.08 mm |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 5.08 mm |
| Number of Terminals | 4 |
| Current Rating | 6.5 A |
| Number of Circuits | 4 |
| Orientation | Right Angle, Vertical |
| Color | Beige |
| Gender | Pin (Male) |
| Number of Contacts | 4 |
| Connector Type | Header |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Number of Ports | 1 |
| Fastening Type | Ramp |
| Max Voltage Rating (AC) | 250 V |
| Housing Color | Beige |
| Plating | Tin |
| Contact Mating Length | 4.3434 mm |
| Country of Origin | SG |
| Mating Post Length | 4.3 mm |
| Termination Post Length | 3.56 mm |
