15EDGKM-3.81-04P-14-1000A(H)
Manufacturer:
Degson
Mfr.Part #:
15EDGKM-3.81-04P-14-1000A(H)
Datasheet:
Description:
Terminal Blocks Plug-In 4 3.81 mm 8 A 300 V 28 AWG to 16 AWG
| Parameter | Value |
|---|---|
| Color | Green |
| Number of Positions | 4 |
| Pitch | 3.81 mm |
| Current Rating | 8 A |
| Voltage Rating | 300 V |
| Voltage Rating (IEC) | 250 V |
| Current Rating (IEC) | 7 A |
| Termination | Copper Alloy |
| Packaging | Bag |
| RoHS | Compliant |
| Wire Gauge Range | 28 AWG to 16 AWG |
| Connection Method | Plug |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 105 °C |
Stock: 399
Distributors
pcbx
pcbxUnit Price$0.74285
Ext.Price$0.74285
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.74285 | $0.74285 |
| 10 | $0.59222 | $5.92220 |
| 25 | $0.54922 | $13.73050 |
| 50 | $0.50934 | $25.46700 |
| 100 | $0.47235 | $47.23500 |
| 300 | $0.43805 | $131.41500 |
| 500 | $0.40624 | $203.12000 |
| 1000 | $0.37675 | $376.75000 |
