16PK47MEFC5X11
Manufacturer:
Rubycon
Mfr.Part #:
16PK47MEFC5X11
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial,5.00mm×11.00mm Through Hole 47 µF 20 % 16 V
| Parameter | Value |
|---|---|
| Capacitance | 47 µF |
| Voltage Rating (DC) | 16 V |
| Tolerance | 20 % |
| Life (Hours) | 2000 Hours |
| Ripple Current | 115 mA |
| Height - Seated (Max) | 12.5 mm |
| Termination | Radial |
| Diameter | 5 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Height | 11 mm |
| Packaging | Bulk |
| Voltage Rating | 16 V |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 2.0066 mm |
| Ripple Current @ Low Frequency | 115 mA @ 120 Hz |
| Ripple Current @ High Frequency | 172.5 mA @ 10 kHz |
Stock: 553
Distributors
pcbx
pcbxUnit Price$0.12484
Ext.Price$0.12484
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.12484 | $0.12484 |
| 10 | $0.07574 | $0.75740 |
| 50 | $0.05431 | $2.71550 |
| 100 | $0.04749 | $4.74900 |
| 500 | $0.03573 | $17.86500 |
| 1000 | $0.03199 | $31.99000 |
| 3000 | $0.02731 | $81.93000 |
| 5000 | $0.02498 | $124.90000 |
