172064-0004
Manufacturer:
Molex
Mfr.Part #:
172064-0004
Datasheet:
Description:
Headers and Wire Housings Through Hole Male Pin Number of Positions:4 Pitch:5.7 mm
| Parameter | Value |
|---|---|
| Length | 12.05 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 4 |
| Voltage Rating | 600 V |
| Halogen Free | Low Halogen |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Contact Plating | Gold |
| Lead Length | 3.6 mm |
| Contact Material(Contact Finish) | Copper |
| Pitch | 5.7 mm |
| Number of Terminals | 4 |
| Current Rating | 23 A |
| Flammability Rating | UL94 V-0 |
| Number of Circuits | 4 |
| Orientation | Right Angle |
| Lifecycle Status | Production (Last Updated: 11 months ago) |
| Color | Black |
| Gender | Male |
| Number of Contacts | 4 |
| Connector Type | Male Pin |
| Number of Positions | 4 |
| Number of Rows | 2 |
| Row Spacing | 5.6896 mm |
| Housing Material | Thermoplastic |
| Number of Ports | 1 |
| Fastening Type | Ramp |
| Plating | Tin |
| glow wire compliant | Compliant |
| Contact Gender | Male |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 11 months ago) |
| Country of Origin | CN |
| Packaging | Tray |
| Termination Post Length | 3.6 mm |
Stock: 1779
Distributors
pcbx
pcbxUnit Price$2.26556
Ext.Price$2.26556
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $2.26556 | $2.26556 |
| 10 | $1.92787 | $19.27870 |
| 25 | $1.88341 | $47.08525 |
| 50 | $1.87743 | $93.87150 |
| 100 | $1.60813 | $160.81300 |
| 300 | $1.57006 | $471.01800 |
| 500 | $1.53289 | $766.44500 |
| 1000 | $1.47732 | $1477.32000 |
