1757022
Manufacturer:
Phoenix Contact
Mfr.Part #:
1757022
Datasheet:
Description:
Terminal Blocks Through Hole 3 5.08 mm 15 A 300 V 30 AWG to 12 AWG
| Parameter | Value |
|---|---|
| Termination | Screw - Rising Cage Clamp |
| Max Operating Temperature | 120 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bulk |
| Voltage Rating | 300 V |
| RoHS | Compliant |
| Voltage | 250 V |
| Contact Plating | Tin |
| Pitch | 5.08 mm |
| Current Rating | 15 A |
| Flammability Rating | UL94V-0 |
| Color | Green |
| Gender | Male |
| Number of Contacts | 3 |
| Mounting Style | Screw |
| lead free status | Lead Free |
| rohs status | Compliant |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Insulation Material | Nylon |
| Housing Material | Nylon |
| Number of Positions Per Level | 3 |
| Number of Levels | 1 |
| size width | 18.2 mm |
| size length | 15.2 mm |
| size height | 15.0 mm |
| voltage rating ac | 250 V |
| Housing Color | Green |
| pin pitch | 5.08 mm |
| Wire Gauge | 24 AWG to 12 AWG |
| Connection Method | Screw |
| Wire Gauge Range | 30 AWG to 12 AWG |
| Current Rating (IEC) | 12 A |
| Voltage Rating (IEC) | 250 V |
Stock: 12
Distributors
pcbx
pcbxUnit Price$1.01386
Ext.Price$1.01386
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.01386 | $1.01386 |
| 10 | $0.82848 | $8.28480 |
| 25 | $0.76461 | $19.11525 |
| 50 | $0.70567 | $35.28350 |
| 100 | $0.65126 | $65.12600 |
| 300 | $0.62285 | $186.85500 |
| 500 | $0.59568 | $297.84000 |
| 1000 | $0.56638 | $566.38000 |
| 3000 | $0.56193 | $1685.79000 |
