22057085
Manufacturer:
Molex
Mfr.Part #:
22057085
Datasheet:
Description:
Headers and Wire Housings Through Hole Male Pin Number of Positions:8 Pitch:2.5 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 250 V |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 250 V |
| Number of Pins | 8 |
| Material | Nylon, Polyamide |
| Packaging | Bulk |
| Voltage Rating | 250 V |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 2.5 mm |
| Insulation Resistance | 1 GΩ |
| REACH SVHC | Unknown |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass |
| Pitch | 2.5 mm |
| Current Rating | 4 A |
| Max Voltage Rating (DC) | 250 V |
| Working Voltage | 250 V |
| Flammability Rating | UL94 V-0 |
| Number of Circuits | 8 |
| Orientation | Right Angle |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Color | Natural |
| Gender | Male |
| Number of Contacts | 8 |
| Number of Poles | 8 |
| Connector Type | Male Pin |
| Wire/Cable Gauge | 22 AWG |
| Number of Positions | 8 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Contact Resistance | 20 mΩ |
| Housing Color | Natural |
| Plating | Tin |
| glow wire compliant | Non-compliant |
| Contact Mating Length | 3.5052 mm |
| Contact Gender | Male |
| Test Voltage | 1 kV |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 8 months ago) |
| Country of Origin | TW |
Stock: 12718
Distributors
pcbx
pcbxUnit Price$0.16896
Ext.Price$0.16896
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.16896 | $0.16896 |
| 10 | $0.14918 | $1.49180 |
| 50 | $0.13171 | $6.58550 |
| 100 | $0.11286 | $11.28600 |
| 500 | $0.09671 | $48.35500 |
| 1000 | $0.09198 | $91.98000 |
| 3000 | $0.08748 | $262.44000 |
| 5000 | $0.08320 | $416.00000 |
