320.02E11BLK
Manufacturer:
E-Switch
Mfr.Part #:
320.02E11BLK
Datasheet:
Description:
Tactile Switches Through Hole SPST-NO Off-Mom 1.2 N Straight
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 50 V |
| Length | 12.5 mm |
| Width | 12.5 mm |
| Termination | PC Pin |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -20 °C |
| Circuit Type | SPST-NO |
| Packaging | Reel |
| RoHS | Compliant |
| Contact Plating | Gold, Silver |
| Contact Material(Contact Finish) | Copper, Silver |
| Current Rating | 25 mA |
| Max Voltage Rating (DC) | 50 V |
| Orientation | Straight |
| Actuator Length | 4 mm |
| Throw Configuration | SPST |
| Housing Material | Nylon |
| Contact Resistance | 50 mΩ |
| Switch Function | Off-Mom |
| Illumination Type | Non-Illuminated |
| Electrical Life | 1 Mcycles |
| Operating Force | 1.2 N |
| Switch Travel | 600 µm |
| Actuator Material | PC, Polycarbonate |
| Mechanical Life | 1 Mcycles |
| Actuator Type | Plunger for Cap |
| Mounting Direction | Straight |
Stock: 271
Distributors
pcbx
pcbxUnit Price$0.85750
Ext.Price$0.85750
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.85750 | $0.85750 |
| 10 | $0.71301 | $7.13010 |
| 25 | $0.70003 | $17.50075 |
| 50 | $0.68729 | $34.36450 |
| 100 | $0.67478 | $67.47800 |
| 300 | $0.66250 | $198.75000 |
| 500 | $0.65044 | $325.22000 |
| 1000 | $0.63860 | $638.60000 |
| 3000 | $0.62698 | $1880.94000 |
| 5000 | $0.61555 | $3077.75000 |
