35RASMT4BHNTRX
Manufacturer:
Switchcraft
Mfr.Part #:
35RASMT4BHNTRX
Datasheet:
Description:
Circular Connectors SMD/SMT Female Solder Phone Connectors
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 12 V |
| Length | 19 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Packaging | Reel |
| Voltage Rating | 250 V |
| Depth | 6 mm |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Contact Plating | Silver |
| Features | Board Guide |
| Contact Material(Contact Finish) | Silver |
| Number of Terminals | 5 |
| Current Rating | 3 A |
| Max Current Rating | 3 A |
| Orientation | Right Angle |
| Color | Black |
| Gender | Female |
| Shielding | Unshielded |
| Connector Type | Phone Connectors |
| Number of Positions | 3 |
| Housing Material | Thermoplastic |
| Number of Ports | 1 |
| Housing Color | Black |
| Contact Gender | Female |
| Shell Material | Thermoplastic |
