35TWL10MEFC5X11
Manufacturer:
Rubycon
Mfr.Part #:
35TWL10MEFC5X11
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial,5.00mm×11.00mm Through Hole 10 µF 20 % 35 V
| Parameter | Value |
|---|---|
| Capacitance | 10 µF |
| Voltage Rating (DC) | 35 V |
| Tolerance | 20 % |
| Life (Hours) | 2000 Hours |
| Ripple Current | 55 mA |
| Height - Seated (Max) | 12.5 mm |
| Diameter | 5 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 2 |
| Height | 11 mm |
| Packaging | Bulk |
| Voltage Rating | 35 V |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Pitch | 2.0066 mm |
| REACH SVHC | Unknown |
| Ripple Current @ Low Frequency | 55 mA @ 120 Hz |
| Ripple Current @ High Frequency | 82.5 mA @ 10 kHz |
Stock: 1420
Distributors
pcbx
pcbxUnit Price$0.17526
Ext.Price$0.17526
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.17526 | $0.17526 |
| 10 | $0.07694 | $0.76940 |
| 50 | $0.07214 | $3.60700 |
| 100 | $0.06763 | $6.76300 |
| 500 | $0.05130 | $25.65000 |
| 1000 | $0.04634 | $46.34000 |
| 3000 | $0.04257 | $127.71000 |
| 5000 | $0.04129 | $206.45000 |
