39-29-3026
Manufacturer:
Molex
Mfr.Part #:
39-29-3026
Datasheet:
Description:
Headers and Wire Housings Through Hole Receptacle Number of Positions:2 Pitch:4.2 mm
| Parameter | Value |
|---|---|
| Length | 5.8 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bulk |
| Depth | 11 mm |
| RoHS | Compliant |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass |
| Pitch | 4.2 mm |
| Current Rating | 6 A |
| Number of Circuits | 2 |
| Orientation | Right Angle, Vertical |
| Lifecycle Status | Production (Last Updated: 11 months ago) |
| Color | Natural |
| Gender | Female |
| Number of Contacts | 2 |
| Connector Type | Receptacle |
| Number of Positions | 2 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Fastening Type | Ramp |
| Contact Resistance | 10 mΩ |
| Plating | Tin |
| Mating Post Length | |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 11 months ago) |
| Country of Origin | US |
| Termination Post Length | 3.5 mm |
Stock: 2885
Distributors
pcbx
pcbxUnit Price$0.31290
Ext.Price$0.31290
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.31290 | $0.31290 |
| 10 | $0.26760 | $2.67600 |
| 25 | $0.26588 | $6.64700 |
| 50 | $0.24589 | $12.29450 |
| 100 | $0.22741 | $22.74100 |
| 300 | $0.21520 | $64.56000 |
| 500 | $0.20364 | $101.82000 |
| 1000 | $0.19270 | $192.70000 |
| 3000 | $0.18235 | $547.05000 |
| 5000 | $0.17256 | $862.80000 |
| 10000 | $0.16329 | $1632.90000 |
