39012020
Manufacturer:
Molex
Mfr.Part #:
39012020
Datasheet:
Description:
Headers and Wire Housings Cable Socket Number of Positions:2 Pitch:4.2 mm
| Parameter | Value |
|---|---|
| Length | 5.4 mm |
| Width | 14.1 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 250 V |
| Number of Pins | 2 |
| Height | 14.1 mm |
| Packaging | Bulk |
| Voltage Rating | 600 V |
| Depth | 19.6 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Contact Material(Contact Finish) | Brass |
| Pitch | 4.2 mm |
| Current Rating | 6 A |
| Max Voltage Rating (DC) | 600 V |
| Flammability Rating | UL94 V-2 |
| Approvals | CSA, TUV, UL |
| Orientation | Straight |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Color | Natural |
| Gender | Receptacle |
| Number of Contacts | 2 |
| Body Material | Nylon, Polyamide |
| Connector Type | Socket |
| Number of Positions | 2 |
| Number of Rows | 2 |
| Row Spacing | 4.2 mm |
| Housing Material | Nylon |
| Contact Resistance | 10 mΩ |
| Max Voltage Rating (AC) | 600 V |
| Housing Color | Natural |
| Schedule B | 8536695050 |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 8 months ago) |
| Country of Origin | US |
