400BXC47MEFC16X25
Manufacturer:
Rubycon
Mfr.Part #:
400BXC47MEFC16X25
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial,16.00mm×25.00mm Through Hole 47 µF 20 % 400 V
| Parameter | Value |
|---|---|
| Capacitance | 47 µF |
| Voltage Rating (DC) | 400 V |
| Tolerance | 20 % |
| Life (Hours) | 12000 Hours |
| Ripple Current | 472 mA |
| Height - Seated (Max) | 27 mm |
| Termination | Radial |
| Diameter | 16 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -25 °C |
| Number of Pins | 2 |
| Height | 25 mm |
| Packaging | Bulk |
| Voltage Rating | 400 V |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Pitch | 7.5 mm |
| REACH SVHC | Unknown |
| Dielectric Material | Aluminium |
| Ripple Current @ Low Frequency | 472 mA @ 120 Hz |
Stock: 3091
Distributors
pcbx
pcbxUnit Price$0.74880
Ext.Price$0.74880
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.74880 | $0.74880 |
| 10 | $0.61843 | $6.18430 |
| 25 | $0.57292 | $14.32300 |
| 50 | $0.53076 | $26.53800 |
| 100 | $0.49169 | $49.16900 |
| 300 | $0.42245 | $126.73500 |
| 500 | $0.36297 | $181.48500 |
| 1000 | $0.34309 | $343.09000 |
