431602105
Manufacturer:
Molex
Mfr.Part #:
431602105
Datasheet:
Description:
Headers and Wire Housings Through Hole Header Number of Positions:5 Pitch:7.49 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 600 V |
| Termination | Solder |
| Diameter | 7.5 mm |
| Max Operating Temperature | 75 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 100 V |
| Number of Pins | 5 |
| Packaging | Tray |
| Voltage Rating | 600 V |
| RoHS | Compliant |
| Lead Pitch | 7.5 mm |
| Insulation Resistance | 1 GΩ |
| REACH SVHC | Unknown |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass |
| Pitch | 7.49 mm |
| Current Rating | 18 A |
| Working Voltage | 600 V |
| Flammability Rating | UL94 V-0 |
| Number of Circuits | 5 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Color | Black |
| Gender | Male |
| Number of Contacts | 5 |
| Connector Type | Header |
| Wire/Cable Gauge | 18 AWG |
| Number of Positions | 5 |
| Number of Rows | 1 |
| Housing Material | Thermoplastic |
| Housing Color | Black |
| Plating | Tin |
| glow wire compliant | Compliant |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 8 months ago) |
| Country of Origin | US |
