436400600
Manufacturer:
Molex
Mfr.Part #:
436400600
Datasheet:
Description:
Headers and Wire Housings Panel, Snap in Male Pin, Plug Number of Positions:6 Pitch:3 mm
| Parameter | Value |
|---|---|
| Length | 18.9 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Height | 3.86 mm |
| Material | Polyester |
| Packaging | Bulk |
| Voltage Rating | 250 V |
| Depth | 24.53 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Contact Plating | Nickel |
| Pitch | 3 mm |
| Max Voltage Rating (DC) | 600 V |
| Flammability Rating | UL94 V-0 |
| Orientation | Straight |
| Operating Supply Voltage | 250 V |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Gender | Male |
| Number of Contacts | 6 |
| Connector Type | Male Pin, Plug |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Housing Material | Polyester |
| Fastening Type | Ramp |
| Housing Color | Black |
| glow wire compliant | Non-compliant |
| Contact Gender | Male |
| Country of Origin | US |
Stock: 612
Distributors
pcbx
pcbxUnit Price$0.27312
Ext.Price$0.27312
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.27312 | $0.27312 |
| 10 | $0.24833 | $2.48330 |
| 50 | $0.22579 | $11.28950 |
| 100 | $0.21024 | $21.02400 |
| 500 | $0.19577 | $97.88500 |
| 1000 | $0.18229 | $182.29000 |
| 3000 | $0.16974 | $509.22000 |
