44764-1002
Manufacturer:
Molex
Mfr.Part #:
44764-1002
Datasheet:
Description:
Headers and Wire Housings Through Hole Header, Receptacle, Socket Number of Positions:10 Pitch:3 mm
| Parameter | Value |
|---|---|
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 10 |
| Voltage Rating | 600 V |
| Halogen Free | Low Halogen |
| Lead Free | Contains Lead |
| Radiation Hardening | No |
| RoHS | Compliant |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Bronze, Gold |
| Pitch | 3 mm |
| Current Rating | 5 A |
| Number of Circuits | 10 |
| Orientation | Right Angle |
| Lifecycle Status | Production (Last Updated: 11 months ago) |
| Color | Black |
| Gender | Female |
| Number of Contacts | 10 |
| Connector Type | Header, Receptacle, Socket |
| Number of Positions | 10 |
| Number of Rows | 2 |
| Row Spacing | 2.9972 mm |
| Housing Material | Polyamide |
| Contact Resistance | 100 mΩ |
| Max Voltage Rating (AC) | 250 V |
| Housing Color | Black |
| Plating | Tin |
| glow wire compliant | Non-compliant |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 11 months ago) |
| Country of Origin | US |
| Packaging | Tray |
Stock: 533
Distributors
pcbx
pcbxUnit Price$3.61123
Ext.Price$3.61123
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $3.61123 | $3.61123 |
| 10 | $3.31713 | $33.17130 |
| 25 | $3.29832 | $82.45800 |
| 50 | $3.29148 | $164.57400 |
| 100 | $3.02901 | $302.90100 |
| 300 | $2.98466 | $895.39800 |
| 500 | $2.94096 | $1470.48000 |
