450MXG390MEFCSN35X35
Manufacturer:
Rubycon
Mfr.Part #:
450MXG390MEFCSN35X35
Datasheet:
Description:
Aluminum Electrolytic Capacitors 35.00mm×35.00mm Through Hole 390 µF 20 % 450 V
| Parameter | Value |
|---|---|
| Capacitance | 390 µF |
| Voltage Rating (DC) | 450 V |
| Tolerance | 20 % |
| Life (Hours) | 3000 Hours |
| Ripple Current | 1.61 A |
| Height - Seated (Max) | 37 mm |
| Termination | Snap in |
| Diameter | 35 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -25 °C |
| Height | 35 mm |
| Packaging | Bulk |
| Voltage Rating | 450 V |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Pitch | 10 mm |
| REACH SVHC | Unknown |
| Ripple Current @ Low Frequency | 1.74 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.436 A @ 10 kHz |
