450MXK390MEFCSN22X60
Manufacturer:
Rubycon
Mfr.Part #:
450MXK390MEFCSN22X60
Datasheet:
Description:
Aluminum Electrolytic Capacitors 22.00mmD×62.00mmH Through Hole 390 µF 20 % 450 V
| Parameter | Value |
|---|---|
| Capacitance | 390 µF |
| Tolerance | 20 % |
| Life (Hours) | 3000 Hours |
| Ripple Current | 2.07 A |
| Height - Seated (Max) | 62 mm |
| Diameter | 22 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -25 °C |
| Packaging | Bulk |
| Voltage Rating | 450 V |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Pitch | 10 mm |
| Schedule B | 8532220040 |
| Ripple Current @ Low Frequency | 2.07 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.898 A @ 10 kHz |
Stock: 117
Distributors
pcbx
pcbxUnit Price$6.42559
Ext.Price$6.42559
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $6.42559 | $6.42559 |
| 10 | $4.59574 | $45.95740 |
| 25 | $4.20063 | $105.01575 |
| 50 | $3.83951 | $191.97550 |
| 100 | $3.62923 | $362.92300 |
| 300 | $3.43047 | $1029.14100 |
| 500 | $3.24259 | $1621.29500 |
| 1000 | $3.06500 | $3065.00000 |
