5023820570
Manufacturer:
Molex
Mfr.Part #:
5023820570
Datasheet:
Description:
Headers and Wire Housings SMD/SMT Forked, Receptacle Number of Positions:5 Pitch:1.25 mm
| Parameter | Value |
|---|---|
| Length | 9.6 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Voltage Rating (AC) | 50 V |
| Number of Pins | 5 |
| Material | Polybutylene |
| Packaging | Reel |
| Voltage Rating | 50 V |
| Depth | 5.95 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Insulation Resistance | 100 MΩ |
| REACH SVHC | Unknown |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Copper |
| Pitch | 1.25 mm |
| Current Rating | 1 A |
| Max Voltage Rating (DC) | 50 V |
| Flammability Rating | UL94 V-0 |
| Number of Circuits | 5 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Color | Natural |
| Gender | Receptacle |
| Number of Contacts | 5 |
| Connector Type | Forked, Receptacle |
| Number of Positions | 5 |
| Number of Rows | 1 |
| Housing Material | Thermoplastic |
| Fastening Type | Latch |
| Contact Resistance | 20 mΩ |
| Max Voltage Rating (AC) | 50 V |
| Housing Color | Natural |
| Plating | Tin |
| glow wire compliant | Non-compliant |
| Contact Gender | Female |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 8 months ago) |
| Country of Origin | MY |
Stock: 16548
Distributors
pcbx
pcbxUnit Price$0.41309
Ext.Price$0.41309
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.41309 | $0.41309 |
| 10 | $0.34848 | $3.48480 |
| 25 | $0.32999 | $8.24975 |
| 50 | $0.31248 | $15.62400 |
| 100 | $0.29589 | $29.58900 |
| 300 | $0.27954 | $83.86200 |
| 500 | $0.26409 | $132.04500 |
| 1000 | $0.24301 | $243.01000 |
