52207-0633
Manufacturer:
Molex
Mfr.Part #:
52207-0633
Datasheet:
Description:
FFC / FPC SMD/SMT Number of Positions:6 1 A 125 V
| Parameter | Value |
|---|---|
| Length | 12.3 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -30 °C |
| Number of Pins | 6 |
| Packaging | Reel |
| Voltage Rating | 125 V |
| Depth | 7.6 mm |
| RoHS | Compliant |
| Insulation Resistance | 100 MΩ |
| REACH SVHC | Unknown |
| Contact Plating | Tin, Silver |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 1 mm |
| Current Rating | 1 A |
| Flammability Rating | UL94 V-0 |
| Number of Circuits | 6 |
| Orientation | Right Angle |
| Lifecycle Status | Production (Last Updated: 11 months ago) |
| Gender | Receptacle |
| Number of Contacts | 6 |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Contact Location | Top |
| Contact Resistance | 20 mΩ |
| Housing Color | White |
| Stackable | No |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 11 months ago) |
| Country of Origin | MY |
