525592452
Manufacturer:
Molex
Mfr.Part #:
525592452
Datasheet:
Description:
FFC / FPC SMD/SMT Number of Positions:24 500 mA 50 V
| Parameter | Value |
|---|---|
| Length | 17.7 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 50 V |
| Material | Bronze |
| Packaging | Reel |
| Voltage Rating | 50 V |
| Depth | 3.5 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Bronze |
| Pitch | 500 µm |
| Current Rating | 500 mA |
| Max Voltage Rating (DC) | 50 V |
| Flammability Rating | UL94 V-0 |
| Number of Circuits | 24 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Gender | Female |
| Number of Contacts | 24 |
| ELV | Compliant |
| Number of Positions | 24 |
| Number of Rows | 1 |
| Housing Material | Nylon |
| Contact Resistance | 20 mΩ |
| Max Voltage Rating (AC) | 50 V |
| Housing Color | Natural |
| Plating | Tin |
| Stackable | No |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 8 months ago) |
| Country of Origin | MY |
| Mounting Angle | Vertical |
