559172230
Manufacturer:
Molex
Mfr.Part #:
559172230
Datasheet:
Description:
Headers and Wire Housings Through Hole Header Number of Positions:22 Pitch:2 mm
| Parameter | Value |
|---|---|
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Packaging | Tray |
| RoHS | Compliant |
| Lead Pitch | 2 mm |
| Contact Plating | Tin |
| Pitch | 2 mm |
| Current Rating | 3 A |
| Number of Circuits | 22 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Color | White |
| Gender | Male Pin |
| Number of Contacts | 22 |
| Connector Type | Header |
| Number of Positions | 22 |
| Number of Rows | 2 |
| Row Spacing | 5 mm |
| Plating | Tin |
| Mating Post Length | 3.81 mm |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 8 months ago) |
| Country of Origin | VN |
| Termination Post Length | 3.2 mm |
Stock: 1
Distributors
pcbx
pcbxUnit Price$1.51066
Ext.Price$1.51066
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.51066 | $1.51066 |
| 10 | $1.48022 | $14.80220 |
| 25 | $1.47117 | $36.77925 |
| 50 | $1.46218 | $73.10900 |
| 100 | $1.45325 | $145.32500 |
