59170-1-T-00-D
Manufacturer:
Littelfuse
Mfr.Part #:
59170-1-T-00-D
Datasheet:
Description:
Switches Screw SPST-NO Voltage Rating (DC):200 V Voltage Rating (AC):140 V
| Parameter | Value |
|---|---|
| Capacitance | 300 fF |
| Voltage Rating (DC) | 200 V |
| Length | 11.43 mm |
| Termination | Gull Wing |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 140 V |
| Power Rating | 10 W |
| Circuit Type | SPST-NO |
| Packaging | Bulk |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Operating Supply Voltage | 200 V |
| Lifecycle Status | Production (Last Updated: 11 months ago) |
| Throw Configuration | SPST |
| Nominal Supply Current | 500 mA |
| Contact Resistance | 100 mΩ |
| Illumination Type | Non-Illuminated |
| Operate Time | 1 ms |
| Release Time | 500 µs |
| Termination Style | Gull Wing |
