60A103C
Manufacturer:
Murata
Mfr.Part #:
60A103C
Datasheet:
Description:
Fixed Inductors 22.00mmL×19.00mmW×12.00mmH SMD/SMT 10.2 µH 10 % 12 A 7 mΩ
| Parameter | Value |
|---|---|
| Tolerance | 10 % |
| Height - Seated (Max) | 11.99 mm |
| Length | 22 mm |
| Width | 18.9992 mm |
| Termination | SMD/SMT |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 3 |
| Composition(Kit Type) | Wirewound |
| Height | 12 mm |
| Packaging | Reel |
| Depth | 19 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Self Resonant Frequency | 21 MHz |
| Current Rating | 12 A |
| DC Resistance (DCR) | 7 mΩ |
| Test Frequency | 100 kHz |
| Military Standard | Not |
| Shielding | Unshielded |
| Inductance | 10.2 µH |
| RMS Current (Irms) | 12 A |
| inductance tolerance | 10 % |
| Max DC Current | 12 A |
| DC Current | 12 A |
| Saturation Current | 17 A |
| Type | Wirewound |
Stock: 137
Distributors
pcbx
pcbxUnit Price$1.18920
Ext.Price$1.18920
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.18920 | $1.18920 |
| 10 | $1.18920 | $11.89200 |
| 25 | $1.18920 | $29.73000 |
| 50 | $1.18920 | $59.46000 |
| 100 | $1.18920 | $118.92000 |
