6100-101K-RC
Manufacturer:
Bourns
Mfr.Part #:
6100-101K-RC
Datasheet:
Description:
Fixed Inductors 11.00mmD×10.50mmH Through Hole 100 µH 10 % 1.98 A 150 mΩ
| Parameter | Value |
|---|---|
| Tolerance | 10 % |
| Height - Seated (Max) | 10.5 mm |
| Length | 10.5 mm |
| Termination | Radial |
| Diameter | 11 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Height | 10.5 mm |
| Packaging | Tray |
| RoHS | Compliant |
| Lead Pitch | 6 mm |
| Contact Plating | Tin |
| Lead/Base Style | Radial |
| Self Resonant Frequency | 5.8 MHz |
| Q Factor | 5.8 |
| Current Rating | 1.98 A |
| DC Resistance (DCR) | 150 mΩ |
| Test Frequency | 100 kHz |
| Military Standard | Not |
| Shielding | Unshielded |
| Inductance | 100 µH |
| Core Material | Ferrite |
| Max DC Current | 1.98 A |
| DC Current | 1.98 A |
| Schedule B | 8504500000 |
| Type | Wirewound |
Stock: 2586
Distributors
pcbx
pcbxUnit Price$0.48817
Ext.Price$0.48817
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.48817 | $0.48817 |
| 10 | $0.40267 | $4.02670 |
| 25 | $0.35137 | $8.78425 |
| 50 | $0.33474 | $16.73700 |
| 100 | $0.31889 | $31.88900 |
| 300 | $0.30509 | $91.52700 |
| 500 | $0.29189 | $145.94500 |
| 1000 | $0.27926 | $279.26000 |
| 3000 | $0.26718 | $801.54000 |
| 5000 | $0.25563 | $1278.15000 |
