63SXV33M
Manufacturer:
Panasonic
Mfr.Part #:
63SXV33M
Datasheet:
Description:
Polymer Capacitors SMD,8.00mm×11.90mm SMD/SMT 33 µF 20 % 63 V
| Parameter | Value |
|---|---|
| Capacitance | 33 µF |
| Voltage Rating (DC) | 63 V |
| Tolerance | 20 % |
| ESR (Equivalent Series Resistance) | 25 mΩ |
| Life (Hours) | 5000 Hours |
| Ripple Current | 2.95 A |
| Height - Seated (Max) | 12 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Packaging | Reel |
| Voltage Rating | 63 V |
| RoHS | Compliant |
| Polarity | Polar |
| REACH SVHC | No SVHC |
| Lifecycle Status | Production (Last Updated: 5 months ago) |
| Schedule B | 8532220020 |
| Ripple Current @ Low Frequency | 147.5 mA @ 120 Hz |
| Ripple Current @ High Frequency | 2.95 A @ 100 kHz |
Stock: 72
Distributors
pcbx
pcbxUnit Price$1.97147
Ext.Price$1.97147
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $1.97147 | $1.97147 |
| 10 | $1.10799 | $11.07990 |
| 25 | $1.07782 | $26.94550 |
| 50 | $1.04847 | $52.42350 |
| 100 | $1.01993 | $101.99300 |
| 300 | $0.91309 | $273.92700 |
| 500 | $0.81744 | $408.72000 |
| 1000 | $0.73182 | $731.82000 |
