63YXJ470M12.5X25
Manufacturer:
Rubycon
Mfr.Part #:
63YXJ470M12.5X25
Datasheet:
Description:
Aluminum Electrolytic Capacitors Radial,12.50mm×25.00mm Through Hole 470 µF 20 % 63 V
| Parameter | Value |
|---|---|
| Capacitance | 470 µF |
| Voltage Rating (DC) | 63 V |
| Tolerance | 20 % |
| Life (Hours) | 10000 Hours |
| Ripple Current | 1.99 A |
| Height - Seated (Max) | 27 mm |
| Termination | Radial |
| Diameter | 12.5 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Leakage Current | 3 µA |
| Height | 25 mm |
| Packaging | Bulk |
| Voltage Rating | 63 V |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Polarity | Polar |
| Lead Diameter | 600 µm |
| Lead Pitch | 5 mm |
| Voltage | 63 V |
| REACH SVHC | No SVHC |
| Impedance | 43 mΩ |
| Ripple Current @ Low Frequency | 1.493 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.99 A @ 100 kHz |
Stock: 222
Distributors
pcbx
pcbxUnit Price$0.37344
Ext.Price$0.37344
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.37344 | $0.37344 |
| 10 | $0.29213 | $2.92130 |
| 50 | $0.25121 | $12.56050 |
| 100 | $0.21602 | $21.60200 |
| 500 | $0.19623 | $98.11500 |
| 1000 | $0.18411 | $184.11000 |
