65043-034LF
Manufacturer:
Amphenol
Mfr.Part #:
65043-034LF
Datasheet:
Description:
Headers and Wire Housings Cable, Free Hanging Receptacle, Socket Number of Positions:6 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Length | 7.62 mm |
| Width | 13.85 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Material | Polyphenylene |
| Packaging | Bulk |
| Voltage Rating | 1000 V (1 kV) |
| Depth | 13.84 mm |
| RoHS | Compliant |
| Lead Pitch | 2.54 mm |
| Insulation Resistance | 100 GΩ |
| REACH SVHC | No SVHC |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Flammability Rating | UL94 V-0 |
| Approvals | CSA, UL |
| Orientation | Straight |
| Color | Black |
| Gender | Receptacle |
| Number of Contacts | 6 |
| Connector Type | Receptacle, Socket |
| Number of Positions | 6 |
| Number of Rows | 2 |
| Row Spacing | 2.54 mm |
| Housing Material | Polyphenylene |
| Max Voltage Rating (AC) | 1000 V (1 kV) |
| Wire Gauge (Max) | 22 AWG |
| Wire Gauge (Min) | 36 AWG |
| Housing Color | Black |
| Contact Gender | Female |
| Schedule B | 8536695050 |
Stock: 9238
Distributors
pcbx
pcbxUnit Price$0.77549
Ext.Price$0.77549
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.77549 | $0.77549 |
| 10 | $0.65686 | $6.56860 |
| 25 | $0.61561 | $15.39025 |
| 50 | $0.58618 | $29.30900 |
| 100 | $0.55820 | $55.82000 |
| 300 | $0.52736 | $158.20800 |
| 500 | $0.49822 | $249.11000 |
| 1000 | $0.47443 | $474.43000 |
| 3000 | $0.43905 | $1317.15000 |
