722RA
Manufacturer:
Switchcraft
Mfr.Part #:
722RA
Datasheet:
Description:
Power Connectors Through Hole Current Rating:5 A Voltage Rating:12 V Pin, Power Male
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 12 V |
| Length | 9.5 mm |
| Termination | Solder |
| Material | Plastic |
| Packaging | Bulk |
| Voltage Rating | 12 V |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Insulation Resistance | 1 GΩ |
| REACH SVHC | No SVHC |
| Contact Plating | Nickel |
| Contact Material(Contact Finish) | Brass |
| Pitch | 3.3 mm |
| Number of Terminals | 3 |
| Current Rating | 5 A |
| Max Current Rating | 5 A |
| Max Voltage Rating (DC) | 12 V |
| Orientation | Right Angle |
| Color | Silver |
| Gender | Male |
| Shielding | Unshielded |
| Number of Contacts | 2 |
| Number of Poles | 3 |
| Connector Type | Pin, Power |
| Number of Positions | 2 |
| Housing Material | Thermoplastic |
| Number of Ports | 1 |
| Contact Resistance | 10 mΩ |
| Housing Color | Black |
| Contact Gender | Female |
| Schedule B | 8536695050 |
Stock: 1743
Distributors
pcbx
pcbxUnit Price$2.79733
Ext.Price$2.79733
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $2.79733 | $2.79733 |
| 10 | $2.55367 | $25.53670 |
| 25 | $2.34790 | $58.69750 |
| 50 | $2.15870 | $107.93500 |
| 100 | $2.07150 | $207.15000 |
| 300 | $2.00149 | $600.44700 |
| 500 | $1.93385 | $966.92500 |
| 1000 | $1.80817 | $1808.17000 |
