78171-0003
Manufacturer:
Molex
Mfr.Part #:
78171-0003
Datasheet:
Description:
Headers and Wire Housings SMD/SMT Plug Number of Positions:3 Pitch:1.2 mm
| Parameter | Value |
|---|---|
| Length | 5.4 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -25 °C |
| Voltage Rating (AC) | 50 V |
| Number of Pins | 3 |
| Packaging | Reel |
| Voltage Rating | 50 V |
| Depth | 4.5 mm |
| Halogen Free | Low Halogen |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Copper |
| Pitch | 1.2 mm |
| Current Rating | 1.5 A |
| Max Voltage Rating (DC) | 5.05 kV |
| Number of Circuits | 3 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 11 months ago) |
| Gender | Pin (Male) |
| Number of Contacts | 3 |
| Connector Type | Plug |
| Number of Positions | 3 |
| Number of Rows | 1 |
| Housing Material | Polymer |
| Contact Resistance | 20 mΩ |
| Max Voltage Rating (AC) | 50 V |
| Housing Color | Black |
| Plating | Gold |
| glow wire compliant | Non-compliant |
| Contact Gender | Male |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 11 months ago) |
| Country of Origin | MY |
Stock: 37351
Distributors
pcbx
pcbxUnit Price$0.22570
Ext.Price$0.22570
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.22570 | $0.22570 |
| 10 | $0.19065 | $1.90650 |
| 50 | $0.17598 | $8.79900 |
| 100 | $0.16244 | $16.24400 |
| 500 | $0.14813 | $74.06500 |
| 1000 | $0.13508 | $135.08000 |
| 3000 | $0.12290 | $368.70000 |
| 5000 | $0.11182 | $559.10000 |
| 10000 | $0.10174 | $1017.40000 |
