874370643
Manufacturer:
Molex
Mfr.Part #:
874370643
Datasheet:
Description:
Headers and Wire Housings SMD/SMT Header Number of Positions:6 Pitch:1.5 mm
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 350 V |
| Length | 10.3 mm |
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Voltage Rating (AC) | 350 V |
| Number of Pins | 6 |
| Height | 5.95 mm |
| Packaging | Reel |
| Voltage Rating | 250 V |
| Depth | 4.45 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Lead Pitch | 1.5 mm |
| Insulation Resistance | 1 GΩ |
| REACH SVHC | Unknown |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass |
| Pitch | 1.5 mm |
| Current Rating | 2.5 A |
| Flammability Rating | UL94 V-0 |
| Number of Circuits | 6 |
| Orientation | Vertical |
| Lifecycle Status | Production (Last Updated: 8 months ago) |
| Color | Beige |
| Gender | Male |
| Number of Contacts | 6 |
| Connector Type | Header |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Housing Material | Polyamide |
| Contact Resistance | 40 mΩ |
| Housing Color | Beige |
| Plating | Tin |
| glow wire compliant | Non-compliant |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 8 months ago) |
| Country of Origin | SG |
Stock: 5992
Distributors
pcbx
pcbxUnit Price$0.31680
Ext.Price$0.31680
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.31680 | $0.31680 |
| 10 | $0.28809 | $2.88090 |
| 50 | $0.26198 | $13.09900 |
| 100 | $0.24389 | $24.38900 |
| 500 | $0.22705 | $113.52500 |
| 1000 | $0.21136 | $211.36000 |
| 3000 | $0.20154 | $604.62000 |
| 5000 | $0.19218 | $960.90000 |
