95503-2441
Manufacturer:
Molex
Mfr.Part #:
95503-2441
Datasheet:
Description:
Modular / Ethernet Connectors Through Hole RJ9 Female Current Rating:1.5 A Voltage Rating:125 V
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 125 V |
| Length | 11.18 mm |
| Width | 15.7 mm |
| Termination | Through Hole |
| Max Operating Temperature | 80 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 4 |
| Height | 15.85 mm |
| Packaging | Tray |
| Voltage Rating | 125 V |
| Depth | 15.08 mm |
| Halogen Free | Low Halogen |
| Lead Free | Lead Free |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Contact Plating | Gold |
| Contact Material(Contact Finish) | Brass, Copper, Gold |
| Pitch | 2.54 mm |
| Current Rating | 1.5 A |
| Max Voltage Rating (DC) | 125 V |
| Orientation | Straight |
| Lifecycle Status | Production (Last Updated: 11 months ago) |
| Color | Black |
| Gender | Female |
| Shielding | Unshielded |
| Number of Contacts | 4 |
| Direction(Counting Sequence) | |
| Number of Positions | 4 |
| Housing Material | Thermoplastic |
| Number of Ports | 1 |
| Housing Color | Black |
| Plating | Tin |
| Number of Positions Loaded | 4 |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 11 months ago) |
| Country of Origin | IE |
| Mounting Angle | Vertical |
| Performance Category | Cat 3 |
| Accessory Type | |
| USOC Codes | RJ9 |
| Number of Positions/Contacts | 4P4C |
Stock: 1640
Distributors
pcbx
pcbxUnit Price$0.76345
Ext.Price$0.76345
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.76345 | $0.76345 |
| 10 | $0.65060 | $6.50600 |
| 25 | $0.61042 | $15.26050 |
| 50 | $0.56426 | $28.21300 |
| 100 | $0.53084 | $53.08400 |
| 300 | $0.49940 | $149.82000 |
| 500 | $0.46982 | $234.91000 |
| 1000 | $0.44200 | $442.00000 |
