A5W-K
Manufacturer:
Fujitsu
Mfr.Part #:
A5W-K
Datasheet:
Description:
Signal Relays Through Hole 28.09 mA Non-Latching Coil Voltage (DC):5 V
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 110 V |
| Length | 14 mm |
| Termination | Solder |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 125 V |
| Number of Pins | 10 |
| Height | 5 mm |
| Packaging | Tube |
| Depth | 9 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| Manufacturer Package Identifier | A |
| Contact Material(Contact Finish) | Gold, Silver |
| Current Rating | 2 A |
| Number of Contacts | 2 |
| Throw Configuration | DPDT |
| Contact Resistance | 50 mΩ |
| Coil Voltage (DC) | 5 V |
| Coil Current | 28.09 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 178 Ω |
| Relay Type | Miniature |
| Operate Time | 6 ms |
| Contact Current Rating | 2 A |
| switching current | 2 A |
| power consumption | 140 mW |
| Switching Voltage | 250 VAC, 220 VDC |
| Coil Power | 140 mW |
| Must Operate Voltage | 3.75 V |
| Must Release Voltage | 500 mV |
| Contact Form | 2 Form C (DPDT-NO, NC) |
