APHHS1005SECK
Manufacturer:
Kingbright
Mfr.Part #:
APHHS1005SECK
Datasheet:
Description:
LEDs 0402(1005 Metric) SMD/SMT Orange 601 nm 20 mA 2.1 V
| Parameter | Value |
|---|---|
| Length | 1 mm |
| Width | 500 µm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Case Code (Imperial) | 0402 |
| Case Code (Metric) | 1005 |
| Number of Pins | 2 |
| Height | 600 µm |
| Packaging | Reel |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Forward Current | 20 mA |
| Forward Voltage | 2.1 V |
| Color | Orange |
| Illumination Color | Orange |
| Lens Style | Clear, Flat |
| Luminous Intensity | 150 mcd |
| Number of LEDs | 1 |
| Viewing Angle | 120 ° |
| Wavelength | 601 nm |
| Lens Transparency | Water Clear |
| Lens Color | Clear |
| Dominant Wavelength/CCT (K) | 601 nm |
| Test Current | 20 mA |
| Schedule B | 8541402000 |
Stock: 528
Distributors
pcbx
pcbxUnit Price$0.18365
Ext.Price$0.18365
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.18365 | $0.18365 |
| 10 | $0.16093 | $1.60930 |
| 50 | $0.14102 | $7.05100 |
| 100 | $0.11933 | $11.93300 |
| 500 | $0.10098 | $50.49000 |
| 1000 | $0.09290 | $92.90000 |
| 3000 | $0.08546 | $256.38000 |
