865609PLTXLF
Manufacturer:
Amphenol
Mfr.Part #:
865609PLTXLF
Datasheet:
Description:
D-Sub Connectors Panel Plug Number of Positions:9 Crimp Male
| Parameter | Value |
|---|---|
| Voltage Rating (DC) | 1 kV |
| Length | 30.43 mm |
| Width | 12.17 mm |
| Termination | Crimp |
| Max Operating Temperature | 125 °C |
| Min Operating Temperature | -55 °C |
| Voltage Rating | 1000 V (1 kV) |
| Depth | 17.35 mm |
| Radiation Hardening | No |
| REACH SVHC | No SVHC |
| Dielectric Material | Thermoplastic |
| Contact Plating | Tin |
| Pitch | 2.74 mm |
| Type | Plug |
| Current Rating | 5 A |
| Orientation | Straight |
| Gender | Male |
| Number of Contacts | 9 |
| Body Material | Metal, Steel |
| Connector Type | D-Sub, Plug, Signal |
| Contact Type | Plug for Male Contacts |
| Number of Positions | 9 |
| Number of Rows | 2 |
| Housing Material | Steel |
| Max Voltage Rating (AC) | 1000 V (1 kV) |
| RoHS | Compliant |
| Packaging | Bulk |
| Shell Material | Steel |
Stock: 1090
Distributors
pcbx
pcbxUnit Price$0.53177
Ext.Price$0.53177
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.53177 | $0.53177 |
| 10 | $0.44114 | $4.41140 |
| 25 | $0.36506 | $9.12650 |
| 50 | $0.35171 | $17.58550 |
| 100 | $0.33885 | $33.88500 |
| 300 | $0.32646 | $97.93800 |
| 500 | $0.31452 | $157.26000 |
| 1000 | $0.30302 | $303.02000 |
| 3000 | $0.29194 | $875.82000 |
| 5000 | $0.28127 | $1406.35000 |
