B72205S0250K101
Manufacturer:
EPCOS
Mfr.Part #:
B72205S0250K101
Datasheet:
Description:
Varistors 7.00mmD×3.60mmT×8.50mmH Through Hole 850 pF 700 mJ Voltage Rating (AC):25 V Voltage Rating (DC):31 V
| Parameter | Value |
|---|---|
| Capacitance | 850 pF |
| Voltage Rating (DC) | 31 V |
| Tolerance | 10 % |
| Termination | Radial |
| Diameter | 5 mm |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 25 V |
| Packaging | Bulk |
| Depth | 3.6 mm |
| Thickness | 3.6 mm |
| RoHS | Compliant |
| Lead Pitch | 5 mm |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Lead Length | 30 mm |
| Lead/Base Style | Radial |
| Current Rating | 1 A |
| Max Voltage Rating (DC) | 31 V |
| Lifecycle Status | Production (Last Updated: 1 year ago) |
| Clamping Voltage | 77 V |
| Varistor Voltage | 39 V |
| Max Voltage Rating (AC) | 25 V |
| Max Surge Current | 100 A |
| Energy | 700 mJ |
| Clamping Current | 1 A |
| Voltage Tolerance | 10 % |
| Surge Energy Rating | 700 mJ |
| Peak Surge Current | 100 A |
Stock: 4699
Distributors
pcbx
pcbxUnit Price$0.14363
Ext.Price$0.14363
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.14363 | $0.14363 |
| 10 | $0.08550 | $0.85500 |
| 50 | $0.07910 | $3.95500 |
| 100 | $0.07318 | $7.31800 |
| 500 | $0.06386 | $31.93000 |
| 1000 | $0.06010 | $60.10000 |
| 3000 | $0.05752 | $172.56000 |
| 5000 | $0.05505 | $275.25000 |
