C503B-GCS-CY0C0791
Manufacturer:
Wolfspeed
Mfr.Part #:
C503B-GCS-CY0C0791
Datasheet:
Description:
LEDs 5.00mmD×8.80mmH Through Hole Green 527 nm 20 mA 3.2 V
| Parameter | Value |
|---|---|
| Length | 5.8 mm |
| Width | 6.35 mm |
| Max Operating Temperature | 95 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 2 |
| Height | 12.45 mm |
| Packaging | Bulk |
| Depth | 5.8 mm |
| REACH SVHC | Unknown |
| Weight | 4.535924 g |
| Number of Elements | 1 |
| Forward Current | 20 mA |
| Forward Voltage | 3.2 V |
| Lifecycle Status | Production (Last Updated: 10 months ago) |
| Color | Green |
| Illumination Color | Green |
| Lens Style | Dome, Round |
| Luminous Intensity | 12.5 cd |
| Power Dissipation | 120 mW |
| Number of LEDs | 1 |
| Viewing Angle | 30 ° |
| Wavelength | 535 nm |
| Lens Transparency | Clear |
| Lens Color | Clear, Colorless |
| Dominant Wavelength/CCT (K) | 527 nm |
| Reverse Voltage | 5 V |
| Test Current | 20 mA |
| Schedule B | 8541402000 |
| RoHS | Compliant |
