A2547WRA-4P
Manufacturer:
CJT
Mfr.Part #:
A2547WRA-4P
Datasheet:
Description:
Board to Board Connectors Free Hanging Header Number of Positions:4 Number of Rows:1 Pitch:2.54 mm
| Parameter | Value |
|---|---|
| Termination | Solder |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bulk |
| Voltage Rating | 250 V |
| RoHS | Compliant |
| Contact Plating | Gold |
| Pitch | 2.54 mm |
| Current Rating | 3 A |
| Connector Type | Header |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Insulation Material | |
| Housing Material | Brass |
| Fastening Type | |
| Contact Style | |
| Contact Mating Length | |
| Contact Shape | |
| Contact Finish Thickness - Mating | |
| Mounting Angle | Right Angle |
Stock: 1084
Distributors
pcbx
pcbxUnit Price$0.53549
Ext.Price$0.53549
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.53549 | $0.53549 |
| 10 | $0.42806 | $4.28060 |
| 25 | $0.38478 | $9.61950 |
| 50 | $0.34588 | $17.29400 |
| 100 | $0.31091 | $31.09100 |
| 300 | $0.27948 | $83.84400 |
| 500 | $0.25123 | $125.61500 |
