CLX6A-FKB-CJNNRFJBB7A363
Manufacturer:
Wolfspeed
Mfr.Part #:
CLX6A-FKB-CJNNRFJBB7A363
Datasheet:
Description:
LEDs 3.50mmL×3.40mmW×2.80mmH SMD/SMT RGB 470 nm 20 mA 3.2 V
| Parameter | Value |
|---|---|
| Length | 3.5 mm |
| Width | 3.4 mm |
| Max Operating Temperature | 100 °C |
| Min Operating Temperature | -40 °C |
| Number of Pins | 6 |
| Power Rating | 140 mW |
| Height | 2.9 mm |
| Packaging | Reel |
| Depth | 3.4 mm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Number of Elements | 3 |
| Forward Current | 20 mA |
| Forward Voltage | 3.2 V |
| Color | Blue, Green, Red |
| Lens Style | Square |
| Luminous Intensity | 392 mcd |
| Number of LEDs | 1 |
| Viewing Angle | 120 ° |
| Wavelength | 480 nm |
| Lens Transparency | Diffused |
| Lens Color | Clear, White |
| Dominant Wavelength/CCT (K) | 470 nm |
| Reverse Voltage | 5 V |
| Test Current | 20 mA |
| Reverse Voltage (DC) | 5 V |
| Illumination Color | RGB |
