DB128R-7.5-3P-GN-S
Manufacturer:
DORABO
Mfr.Part #:
DB128R-7.5-3P-GN-S
Datasheet:
Description:
Terminal Blocks Through Hole 3 7.5 mm 16 A 30 V 22 AWG to 12 AWG
| Parameter | Value |
|---|---|
| Termination | Tin |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bag |
| Voltage Rating | 30 V |
| RoHS | Compliant |
| Pitch | 7.5 mm |
| Current Rating | 16 A |
| Color | Green |
| Number of Positions | 3 |
| Connection Method | Screw |
| Wire Gauge Range | 22 AWG to 12 AWG |
| Current Rating (IEC) | 24 A |
| Voltage Rating (IEC) | 450 V |
Stock: 99
Distributors
pcbx
pcbxUnit Price$0.14976
Ext.Price$0.14976
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.14976 | $0.14976 |
| 10 | $0.14802 | $1.48020 |
| 50 | $0.14630 | $7.31500 |
| 100 | $0.14468 | $14.46800 |
| 500 | $0.14308 | $71.54000 |
