DB2EK-7.62-2P-GN-S
Manufacturer:
DORABO
Mfr.Part #:
DB2EK-7.62-2P-GN-S
Datasheet:
Description:
Terminal Blocks Through Hole 2 7.62 mm 15 A 300 V 28 AWG to 12 AWG
| Parameter | Value |
|---|---|
| Color | Green |
| Pitch | 7.62 mm |
| Current Rating | 15 A |
| Termination | Tin |
| Packaging | Bag |
| RoHS | Compliant |
| Wire Gauge Range | 28 AWG to 12 AWG |
| Connection Method | Plug |
| Voltage Rating | 300 V |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 105 °C |
| Voltage Rating (IEC) | 400 V |
| Current Rating (IEC) | 15 A |
| Number of Positions | 2 |
Stock: 1492
Distributors
pcbx
pcbxUnit Price$0.31296
Ext.Price$0.31296
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.31296 | $0.31296 |
| 10 | $0.27804 | $2.78040 |
| 50 | $0.24701 | $12.35050 |
| 100 | $0.21173 | $21.17300 |
| 500 | $0.18149 | $90.74500 |
| 1000 | $0.17318 | $173.18000 |
| 3000 | $0.16525 | $495.75000 |
| 5000 | $0.15768 | $788.40000 |
