DB2EKAM-5.08-2P-GN-S
Manufacturer:
DORABO
Mfr.Part #:
DB2EKAM-5.08-2P-GN-S
Datasheet:
Description:
Terminal Blocks Through Hole 2 5.08 mm 15 A 300 V 28 AWG to 14 AWG
| Parameter | Value |
|---|---|
| Color | Green |
| Pitch | 5.08 mm |
| Current Rating | 15 A |
| Termination | Solder |
| RoHS | Compliant |
| Connection Method | Plug |
| Voltage Rating | 300 V |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 105 °C |
| Voltage Rating (IEC) | 250 V |
| Current Rating (IEC) | 15 A |
| Packaging | Bag |
| Wire Gauge Range | 28 AWG to 14 AWG |
| Number of Positions | 2 |
Stock: 62
Distributors
pcbx
pcbxUnit Price$0.25258
Ext.Price$0.25258
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.25258 | $0.25258 |
| 10 | $0.24682 | $2.46820 |
| 25 | $0.24521 | $6.13025 |
| 50 | $0.24361 | $12.18050 |
| 100 | $0.24202 | $24.20200 |
