DB910-9.52-2P-GN-S
Manufacturer:
DORABO
Mfr.Part #:
DB910-9.52-2P-GN-S
Datasheet:
Description:
Terminal Blocks Through Hole 2 9.52 mm 30 A 300 V 26 AWG to 12 AWG
| Parameter | Value |
|---|---|
| Termination | Tin |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -40 °C |
| Packaging | Bag |
| Voltage Rating | 300 V |
| RoHS | Compliant |
| Pitch | 9.52 mm |
| Current Rating | 30 A |
| Color | Green |
| Number of Positions | 2 |
| Connection Method | Screw |
| Wire Gauge Range | 26 AWG to 12 AWG |
| Current Rating (IEC) | 32 A |
| Voltage Rating (IEC) | 630 V |
Stock: 460
Distributors
pcbx
pcbxUnit Price$0.29616
Ext.Price$0.29616
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.29616 | $0.29616 |
| 10 | $0.26062 | $2.60620 |
| 50 | $0.22934 | $11.46700 |
| 100 | $0.19787 | $19.78700 |
| 500 | $0.17072 | $85.36000 |
| 1000 | $0.16224 | $162.24000 |
| 3000 | $0.15418 | $462.54000 |
| 5000 | $0.14651 | $732.55000 |
