DG300-5.0-02P-12-00A(H)
Manufacturer:
Degson
Mfr.Part #:
DG300-5.0-02P-12-00A(H)
Datasheet:
Description:
Terminal Blocks Through Hole 2 5 mm 10 A 300 V 22 AWG to 14 AWG
| Parameter | Value |
|---|---|
| Length | 10 mm |
| Termination | Screw |
| Max Operating Temperature | 120 °C |
| Min Operating Temperature | -30 °C |
| Packaging | Bulk |
| Voltage Rating | 300 V |
| RoHS | Compliant |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Brass |
| Pitch | 5 mm |
| Current Rating | 10 A |
| Flammability Rating | UL94 V-0 |
| Orientation | Right Angle |
| Color | Blue |
| Number of Positions | 2 |
| Connection Method | Screw |
| Wire Gauge Range | 22 AWG to 14 AWG |
| Voltage Rating (IEC) | 250 V |
| Current Rating (IEC) | 24 A |
