DG500-5.08-03P-14-00A(H)
Manufacturer:
Degson
Mfr.Part #:
DG500-5.08-03P-14-00A(H)
Datasheet:
Description:
Terminal Blocks Through Hole 3 5.08 mm 20 A 300 V 30 AWG to 12 AWG
| Parameter | Value |
|---|---|
| Color | Green |
| Number of Positions | 3 |
| Pitch | 5.08 mm |
| Current Rating | 20 A |
| Voltage Rating | 300 V |
| Voltage Rating (IEC) | 250 V |
| Current Rating (IEC) | 18 A |
| Termination | Copper Alloy |
| Packaging | Bag |
| RoHS | Compliant |
| Wire Gauge Range | 30 AWG to 12 AWG |
| Connection Method | Screw |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 105 °C |
Stock: 1045
Distributors
pcbx
pcbxUnit Price$0.36624
Ext.Price$0.36624
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.36624 | $0.36624 |
| 10 | $0.28608 | $2.86080 |
| 50 | $0.24185 | $12.09250 |
| 100 | $0.20446 | $20.44600 |
| 500 | $0.17285 | $86.42500 |
