DSS1NB32A221Q91A
Manufacturer:
Murata
Mfr.Part #:
DSS1NB32A221Q91A
Datasheet:
Description:
EMI / RFI Filters Radial - 3 Leads Through Hole LC 3rd 220 pF
| Parameter | Value |
|---|---|
| Capacitance | 220 pF |
| Voltage Rating (DC) | 100 V |
| Tolerance | 10 % |
| Length | 8.5 mm |
| Width | 3.5 mm |
| Termination | Radial |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Height | 7.5 mm |
| Packaging | Ammo Pack |
| Voltage Rating | 100 V |
| RoHS | Compliant |
| Insulation Resistance | 50 MΩ |
| Current | 6 A |
| Current Rating | 6 A |
| Lifecycle Status | Production (Last Updated: 1 month ago) |
| Number of Channels | 1 |
| Number of Lines | 1 |
| ESD Protection | No |
| Chemistry/Technology | LC |
| Filter Order | 3rd |
Stock: 1702
Distributors
pcbx
pcbxUnit Price$0.34454
Ext.Price$0.34454
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.34454 | $0.34454 |
| 10 | $0.24537 | $2.45370 |
| 25 | $0.23402 | $5.85050 |
| 50 | $0.22320 | $11.16000 |
| 100 | $0.21287 | $21.28700 |
| 300 | $0.20637 | $61.91100 |
| 500 | $0.20006 | $100.03000 |
| 1000 | $0.18124 | $181.24000 |
| 3000 | $0.15730 | $471.90000 |
| 5000 | $0.14622 | $731.10000 |
| 10000 | $0.13593 | $1359.30000 |
