EEE-FK1E331GP
Manufacturer:
Panasonic
Mfr.Part #:
EEE-FK1E331GP
Datasheet:
Description:
Aluminum Electrolytic Capacitors SMD,8.00mm×10.20mm SMD/SMT 330 µF 20 % 25 V
| Parameter | Value |
|---|---|
| Capacitance | 330 µF |
| Voltage Rating (DC) | 25 V |
| Tolerance | 20 % |
| ESR (Equivalent Series Resistance) | 160 mΩ |
| Life (Hours) | 5000 Hours |
| Ripple Current | 600 mA |
| Height - Seated (Max) | 10.2 mm |
| Length | 10.2 mm |
| Width | 10 mm |
| Termination | SMD/SMT |
| Diameter | 8 mm |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Leakage Current | 3 µA |
| Dissipation Factor | 0.14 % |
| Height | 10.2 mm |
| Packaging | Reel |
| Voltage Rating | 25 V |
| Lead Free | Lead Free |
| Radiation Hardening | No |
| RoHS | Compliant |
| Voltage | 25 V |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Impedance | 160 mΩ |
| Ripple Current (AC) | 600 mA |
| Lifecycle Status | Production (Last Updated: 5 months ago) |
| Schedule B | 8532220020 |
| Ripple Current @ Low Frequency | 450 mA @ 120 Hz |
| Ripple Current @ High Frequency | 600 mA @ 100 kHz |
